Go Back   Madabout Kitcars Forum > Mad Build Area > Tribute Automotive Builds

Tribute Automotive Builds Discuss your Tribute kit build

Reply

Thread Tools Display Modes
  #21
Old 16th October 2013, 21:15
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]
Reply With Quote
  #22
Old 16th October 2013, 21:17
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]
Reply With Quote
  #23
Old 16th October 2013, 22:08
Mitchelkitman Mitchelkitman is online now
Senior Member

Join Date: Oct 2013
Location: norfolk
Posts: 479
Mitchelkitman is on a distinguished road
Default

Quote:
Originally Posted by Scottie22 View Post
So I drilled out 130 holes in total,had them shot blasted, and with the
£6000 odd quid I'd saved by not buying the polished ones took them to a paint shop for a good job.
Count again - I make it 120. I admire your patience, it must have taken a lot of time and drill bits. Hope you haven't weakened them too much? Only joking, I'm sure they'll be fine. Look really good. I've also thought steels would be a good alternative to (and a lot cheaper than) wires. I notice a lot of places are selling them for winter wheels - mostly black though, but nothing a coat of paint won't change! Good luck.
Reply With Quote
  #24
Old 16th October 2013, 22:33
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default holes

Yes you are right! 120
Drilling holes is boring.........

It took about an hour per wheel and I still use the same two bits/ hole cutters now
Reply With Quote
  #25
Old 19th October 2013, 21:01
Tribute Automotive's Avatar
Tribute Automotive Tribute Automotive is offline
Senior Member

Join Date: Oct 2010
Posts: 1,622
Tribute Automotive is on a distinguished road
Default

Welcome to the Forum Scottie. Your detailing is something I am really looking forward to. Keep on posting those pictures.
Reply With Quote
  #26
Old 20th October 2013, 13:43
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

While I was waiting for my body shell, I had time to work out what I wanted to achieve and how I was going to do that.
Replicas are by definition frauds, and a lot of so called kit cars fall into this category also.

If a Jaguar based XKSS is a fraud, how fraudulent must a Triumph Spitfire based one
Be?? An incredibly naughty fraud I think!
Fraud it may be, but to be half believable, it must be a damned good one, so attention to detail becomes very important.

An XKSS is an iconic car, and a replica must have all of the salient features that make the car unique. After I finished the wheels to as good a standard as I could on my limited budget, I decide to tackle the very obvious side exhaust.
On the original car, the exhaust is on the left because the XK engine has the manifold that side. Unfortunately the Spitfire has the exhaust manifold on the right, which meant having to get the gasses under the car floor and out to the left side.

Because the finished car will be as low as I can get it, I could not use a large bore pipe
To go under the floor, for obvious reasons, then it occurred to me that I could , if I squashed it almost flat.
I worked out the surface area of the original pipe, squashed a much larger one, which when “flat” would give me a little more area than the original pipe and the problem was solved. All I had to do now was make it.

The whole thing including the silencer box was to be made of stainless steel.

I have tried to show the results in the pictures to follow, its not finished yet, but most of the hard work and problems have been sorted out.

The system is made from discarded stainless steel bits and bobs from my local scrapyard at peanut prices. The most expensive buy was the argon gas needed to weld it all up.
Reply With Quote
  #27
Old 20th October 2013, 13:45
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

Reply With Quote
  #28
Old 20th October 2013, 13:50
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

Reply With Quote
  #29
Old 20th October 2013, 13:52
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]
Reply With Quote
  #30
Old 20th October 2013, 13:55
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]
Reply With Quote
  #31
Old 20th October 2013, 13:56
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]
Reply With Quote
  #32
Old 20th October 2013, 13:57
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]
Reply With Quote
  #33
Old 20th October 2013, 14:05
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]
Reply With Quote
  #34
Old 20th October 2013, 16:31
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

When I was posting the pictures of the wheels earlier on, I forgot to add the pictures of the modified spinners.They were really cheap off ebay, but are quite hefty. They are solid aluminium chromed, and weigh over 630 grams each. I was not happy with the small "toy" bolt which was supposed to hold them in place on the wheel, so I made some small mods,
uprated the bolt, and added a second one, as I just did not trust the way it was designed to stay on!
Reply With Quote
  #35
Old 20th October 2013, 16:32
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]
Reply With Quote
  #36
Old 20th October 2013, 16:33
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]
Reply With Quote
  #37
Old 20th October 2013, 18:05
Mitchelkitman Mitchelkitman is online now
Senior Member

Join Date: Oct 2013
Location: norfolk
Posts: 479
Mitchelkitman is on a distinguished road
Default

Going well - I like you approach to the exhaust...... If there's a way, you'll find it!
Now I'm betting you wrecked the drill bit doing all those holes in the stainless!
Nasty old stuff compared with mild steel (to drill).
Reply With Quote
  #38
Old 20th October 2013, 18:37
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

Someone else said I must have wrecked the drill bits and hole cutters, but they are still in good nick considering what they've been through!
I take your point about stainless steel though, I don't even like welding it!
Reply With Quote
  #39
Old 25th October 2013, 21:16
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default The body

The body finally arrived, and one of the first things I wanted to do was put aluminium louvres in the bonnet.
The original car had I think 6 or 7 inch louvres, but because I chose a non flip front end, it came with an ordinary opening type bonnet, which due to the position and width, the full size louvres would not fit/be practical.
I went to B nQ and they had some cheap ally ones about 4 inches wide which I decided to fit.

The XKSS had more louvres on the nearside as that is where all the heat from the exhaust manifold needed to be vented, so mine had to be similar
to look the part.

[IMG][/IMG]
Reply With Quote
  #40
Old 25th October 2013, 21:21
Scottie22 Scottie22 is offline
Senior Member

Join Date: May 2013
Posts: 2,161
Scottie22 is on a distinguished road
Default

[IMG][/IMG]

[IMG][/IMG]

I cut the holes, routered the edges out about half a mil so the alloy would sit almost flush, stuk them in with epoxy resin, filled and sanded. although there will vbe a lot of rubbing down to be done yet to get a perfect finish for a top coat!
Reply With Quote
